- Products description -
Digital Transmitter---A DFB laser diode is employed for upstream transmission at OC-48(2488Mbps).The optical transmitter includes a back facet photo-detector to monitor laser power for APC control.Digital Receiver---A photo-detector with TIA is employed for downstream data reception at OC-48(2488Mbps).The module data link up to 40KM in 9/125um single mode fiber.They are available in eight different CWDM wavelengths and comply with the ITU CWDM standard The optical output can be disabled by a TTL logic high-level input of Tx Disable,and the system also can disable the module via I2C.Tx Fault is provided to indicate that degradation of the laser.Loss of signal(LOS)output is provided to indicate the loss of an input optical signal of receiver or the link status with partner.The system can also get the LOS(or Link)/Disable/Fault information via I2C register access.
- Product Features -
1.Bi-directional 2.5Gbps Upstream/2.5Gbps Downstream
2.EEPROM with Serial ID Functionality
3.Compliant with SFF-8472
4.Uncooled DFB laser transmitter
5.SFP package with LC/UPC receptacle connect
6.Support Digital Diagnostic Monitoring interface
7.Single+3.3V Power Supply and TTL Logic Interface
8.ROHS-6 compliant
9.Class 1 Product which comply with the requirements of IEC 60825-1 and IEC 60825-2
10.Case operating temperature:-40°C to+85°C
- Product Specification -
SONET OC-48
SDH STM-16
2x fiber channel
Other optical Links
Table 1-Optical and Electrical Characteristics
Parameter | Symbol | Min | Typical | Max | Unit | Notes | ||
Transmitter | ||||||||
Centre Wavelength | λc | 1260 | 1310 | 1360 | nm | |||
Spectral Width(RMS) | ?λ | 4 | nm | |||||
Average Output Power | Pout | -9 | -3 | dBm | 1 | |||
Extinction Ratio | ER | 9 | dB | |||||
Optical Rise/Fall Time(20%~80%) | tr/tf | 0.26 | ns | |||||
Data Input Swing Differential | VIN | 400 | 1800 | mV | 2 | |||
Input Differential Impedance | ZIN | 90 | 100 | 110 | Ω | |||
TX Disable | Disable | 2 | Vcc | V | ||||
Enable | 0 | 0.8 | V | |||||
TX Fault | Fault | 2 | Vcc | V | ||||
Normal | 0 | 0.8 | V | |||||
Receiver | ||||||||
Centre Wavelength | λc | 1260 | 1580 | nm | ||||
Receiver Sensitivity | -23 | dBm | 3 | |||||
Receiver Overload | -3 | dBm | 3 | |||||
LOS De-Assert | LOSD | -24 | dBm | |||||
LOS Assert | LOSA | -35 | dBm | |||||
LOS Hysteresis | 1 | 4 | dB | |||||
Data Output Swing Differential | Vout | 400 | 1800 | mV | 4 | |||
LOS | High | 2 | Vcc | V | ||||
Low | 0.8 | V | ||||||
Notes:
1.The optical power is launched into SMF.
2.PECL input,internally AC-coupled and terminated.
3.Measured with a PRBS 27-1 test pattern@1250Mbps,BER ≤1×10-12.
4.Internally AC-coupled.
Table2-Product selection
Wavelength | xx or yy | Clasp Color Code | Wavelength | xx or yy | Clasp Color Code |
1270 nm | 27 | Gray | 1450 nm | 45 | Brown |
1290 nm | 29 | Gray | 1470 nm | 47 | Gray |
1310 nm | 31 | Gray | 1490 nm | 49 | Purple |
1330nm | 33 | Purple | 1510 nm | 51 | Blue |
1350 nm | 35 | Blue | 1530 nm | 53 | Green |
1370 nm | 37 | Green | 1550 nm | 55 | Yellow |
1390 nm | 39 | Yellow | 1570 nm | 57 | Orange |
1410 nm | 41 | Orange | 1590 nm | 59 | Red |
1430 nm | 43 | Red | 1610 nm | 61 | Brown |
Ordering information
Part No. | Form Factor | Data Rate | Distance | Wavelength | Connector | DDM |
XYT-00854G-S5x(D) | SFP | 4.25G | 500m | 850nm | LC | Y |
XYT-00314G-L1xD | SFP | 4.25G | 10km | 1310nm | LC | Y |
XYT-00314G-L3xD | SFP | 4.25G | 30km | 1310nm | LC | Y |
XYT-00554G-L4XD | SFP | 4.25G | 40km | 1550nm | LC | Y |
XYT-003148-L2x(D) | SFP | 2.5G | 20km | 1310nm | LC | Y |
XYT-008548-S3x(D) | SFP | 2.5G | 300m | 850nm | LC | Y |
XYT-005548-L8x(D) | SFP | 2.5G | 80km | 1550nm | LC | Y |
XYT-003148-L4x(D) | SFP | 2.5G | 40km | 1310nm | LC | Y |
XYT-005548-12CD | SFP | 2.5G | 120km | 1550nm | LC | Y |
XYT-008524-S5x(D) | SFP | 1.25G | 550m | 850nm | LC | Y |
XYT-003124-L2x(D) | SFP | 1.25G | 20km | 1310nm | LC | Y |
XYT-005524-L8C(D) | SFP | 1.25G | 80km | 1550nm | LC | Y |
XYT-003124-L4x(D) | SFP | 1.25G | 40km | 1310nm | LC | Y |
XYT-005524-12C(D) | SFP | 1.25G | 120km | 1550nm | LC | Y |
XYT-003112-L2x(D) | SFP | 622M | 20km | 1310nm | LC | Y |
XYT-003112-L4x(D) | SFP | 622M | 40km | 1310nm | LC | Y |
XYT-008503-02C(D) | SFP | 155M | 2km | 850nm | LC | Y |
XYT-003112-L8x(D) | SFP | 622M | 80km | 1550nm | LC | Y |
XYT-005503-L8CD | SFP | 155M | 80km | 1310nm | LC | Y |
XYT-003103-L2C(D) | SFP | 155M | 20km | 1310nm | LC | Y |
XYT-003103-L4C(D) | SFP | 155M | 40km | 1310nm | LC | Y |
XYT-005503-12CD | SFP | 155M | 120km | 1550nm | LC | Y |
|
Products damaged due to human or non-use of other causes of improper,we promises one year warranty and lifetime maintenance,but the unauthorized disassembly equipment caused damage is not covered under warranty and returned within range. |
|
Under normal use,if there are product quality problems,or not work normally,we provide free repair or replacement service within one year;Within three years more than one year,we provide to collect the material cost,maintenance free. Repair warranty period of three years from the freight borne by each of the parties.After three years of warranty,the material cost,maintenance,freight(refers to the product of the two-way shipping to and from)shall be borne by the user. |
|
We promise that the product we provide can meet the performance requirements of users , and it is supplied by the user's sample request. |
