1.25G OEO optical electrical optical converter

- Products description -

XYT-1000 series OEO converters are used for re-amplifying and re-shaping the signals in the transmission process.It can save optical fiber resources and networking cost effectively,and solves the problem that the transmission distance is too long to transmit.With advantages of small volume optical signal,economy and safety,convenient construction and etc,it is widely used in various optical transmission fields and long-distance trunk transmission.Fiber-to-Fiber media converters extend network distance by converting wavelengths(1310 to 1550),amplifying optical power. transponders as re-generators are also an optical – electrical – optical(O-E-O)converter with electrical amplification of the signal by FEC to realize long distances fiber transmissio.XYT transponders are protocol and rate-transparent fiber media converters that support SFP,SFP+and XFP transceivers with data rates up to 10Gpbs,and our transponders provide seamless integration of different fiber types by converting multi-mode fiber to single-mode fiber,and dual fiber to single-fiber.

- Product Features -

Varieties of devices:Different kinds of Devices are available to meet customers’ different requirement.
Flexible plus transparent access to services at different rates:Provide ports with different rate to support services such as Ethernet,PDH,SDH,ATM,etc.
Trunk type:Wavelength conversion,mode conversion,re-shaping and enlarging optical power.
Trunk transmission distance:10KM,20KM,30KM,50KM,80KM,100KM,120KM or above.
Manageable function：Provide varieties of network manageable mode,including SNMP,Web,CLI and telnet.

- Product Specification -

Conversion between Multi-mode and Single-mode
Conversion between Dual fiber and Single fiber
Conversion between different wavelength

Specification

System parameters			Technical indicators
Rate			100M~1.25G	2.5G	10G
Average Output Power(dBm)			-6~3	-6~3	-5~3
Receiver Sensitivity(dBm)			-23~-32	-22~28	-19~24
Extinction ratio(dB)			≥9	≥10	≥10
wavelength			Singlemode,multimode
Jitter performance			In line with the ITU-T G.825(2000)
The side mode suppression ratio(db)			>30
Fiber Type			G.652 G.653 G.655
ProductSize	Card		25（W）×88（H）×116（D） (mm)
	individua		110（W）×30（H）×140（D） (mm)
	Single-slot chassis		137.5（W）× 36.2（H）× 164.8（D） (mm)
	2U chassis		428（W）× 88（H）× 322（D） (mm)
Environmental requirements	Operating Temperature		-10℃ ~60℃
	Storage Temperature		-40℃ ~80℃
	Relative humidity		5%~95%
Power Requirements(Standard)			220 V/AC， 50Hz；-48 V/DC(Optional)
Safety and EMC			In line with the FCC,UL,CE,TUV,CSA standards
Power consumption		Single desktop	≤ 5W
		2U	≤85W(10G≤150W)

Ordering Information

XYT-OEO	2	X	X	X1X2	XX/XX
	Device type	Rate	Interface Type	Distance relay	Wavelength
	1=Card 2=individua (AC220V) 3=individua (DC-48V) 4=individua (DC-24V	0=155M 1=1.25G 2=2.5G 3=10G 4=40G X=Customize	1=LC 2=SC 3=FC	X1=Left to X2=Right to 1=40KM 2=60KM 3=80KM 4=100KM 5=120KM	XX/XX=custom Example:31/55=1310nm/1550nm

Sale service

	Products damaged due to human or non-use of other causes of improper,we promises one year warranty and lifetime maintenance,but the unauthorized disassembly equipment caused damage is not covered under warranty and returned within range.
	Under normal use,if there are product quality problems,or not work normally,we provide free repair or replacement service within one year;Within three years more than one year,we provide to collect the material cost,maintenance free. Repair warranty period of three years from the freight borne by each of the parties.After three years of warranty,the material cost,maintenance,freight(refers to the product of the two-way shipping to and from)shall be borne by the user.
	We promise that the product we provide can meet the performance requirements of users , and it is supplied by the user's sample request.
