- Product Description -
Dense wavelength division multiplexing uses the wavelength of laser to transmit data in optical fiber according to bit parallel transmission or string line transmission. It uses thin film coating technology and proprietary non flux metal welding micro optical packaging design to realize the uplink and downlink of light within ITU wavelength. DWDM is an important part of optical fiber network. It can transmit e-mail, video, multimedia, data and voice carried under IP protocol, ATM and synchronous optical fiber network / synchronous digital sequence (SONET / SDH) protocol through a unified optical fiber layer.
XYT 100G channel spacing dense optical wavelength division multiplexer / demultiplexer adopts mature multi cavity dielectric film to realize optical filtering, with good wavelength stability, sealed process packaging and high environmental stability.
- Features -
1.48 channels 10GE + 6 channels 100ge optical interface, support SFP + / qsfp28 pluggable optical module and LC optical fiber terminal.
2. Support rates of 10GBASE-R, 40gbase - R4 and 100gbase-lr4, and wavelengths of 850 / 1310 / 1550nm.
3. Support single fiber receiving or single fiber sending of optical module.
4. The optical interface can be configured with input or output at will.
5. It can monitor the output flow at full load, with a total monitoring flow of 1080gbps.
6. Support the data aggregation output of multiple ports, and also support the data of one or more ports to be copied to multiple monitoring ports for output at the same time.
7. Support VLAN and QinQ packet identification and filtering, MPLS label stripping, VLAN field stripping, replacement, addition and other operations.
8. Support load balancing and shunting function, and support blacklist mode or whitelist mode.
9. Support a variety of network management modes, including console and SSH command line mode and Web Chinese and English network management mode.
10. Support remote online upgrade of system software.
|
Products damaged due to human or non-use of other causes of improper,we promises one year warranty and lifetime maintenance,but the unauthorized disassembly equipment caused damage is not covered under warranty and returned within range. |
|
Under normal use,if there are product quality problems,or not work normally,we provide free repair or replacement service within one year;Within three years more than one year,we provide to collect the material cost,maintenance free. Repair warranty period of three years from the freight borne by each of the parties.After three years of warranty,the material cost,maintenance,freight(refers to the product of the two-way shipping to and from)shall be borne by the user. |
|
We promise that the product we provide can meet the performance requirements of users , and it is supplied by the user's sample request. |
