- Product Features -
1. High Precision
2. Wide Attenuation Range
3. Low Return Loss
4. Good Stability and reliability
- Product Specification -
1. Communication System
2. CATV
3. FTTH
4. Power equalization in optical connects
5. Optical Transmission System
Parameter
Parameter | Performance | |
Operating Wavelength (nm) | 1260-1620, 850 | |
Insertion Loss (dB) | < 1.0 | |
Max. Attenuation Range (dB) | 1.0～65.0 | |
Insertion Loss Temperature Sensitivity | <0.5 | |
PDL (dB) | <0.15 | (<15dB attenuation) |
<0.25 | (16~50dB attenuation) | |
Return Loss (dB) | >45 (UPC) | |
>50(APC) | ||
Maximum Power Handling | 500 | |
Operating Temperature | -5 ~+70 | |
Storage Temperature | -40 ~+85 | |
Dimension | 20.8*8.8*5 | |
Order Information
Type | Wavelength | Pigtail Type | Fiber Type | Optical Length | Connector |
A=Attenuator | 1=1260~1620nm 2=850nm 3=1310nm | 0=250um 1=0.9mm Loose tube 2=2mm Cable 3=3mm Cable | 1=SMF-28e 2=50/125 3=62.5/125 | 1=1m 2=1.5m S=Specify | 0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=LC |
|
Products damaged due to human or non-use of other causes of improper,we promises one year warranty and lifetime maintenance,but the unauthorized disassembly equipment caused damage is not covered under warranty and returned within range. |
|
Under normal use,if there are product quality problems,or not work normally,we provide free repair or replacement service within one year;Within three years more than one year,we provide to collect the material cost,maintenance free. Repair warranty period of three years from the freight borne by each of the parties.After three years of warranty,the material cost,maintenance,freight(refers to the product of the two-way shipping to and from)shall be borne by the user. |
|
We promise that the product we provide can meet the performance requirements of users , and it is supplied by the user's sample request. |
